Simulation Element Properties

Sources

Constant

• Value

  • simName.solverName.constantBlockName.Value = vector({num})

Sine/Square/Triangle/Sawtooth/signalGenerator

• Amplitude

  • simName.solverName.blockName.Amplitude = vector({num})

• Bias

  • simName.solverName.blockName.Bias = vector({num})

• Frequency

  • simName.solverName.blockName.Frequency = vector({num})

• Phase

  • simName.solverName.blockName.Phase = vector({num})

Step

• Initial

  • simName.solverName.stepName.InitialValue = vector({num})

• Final

  • simName.solverName.stepName.FinalValue = vector({num})

• Time

  • simName.solverName.stepName.Time = vector({num})

Ramp

• Amplitude

  • simName.solverName.rampName.Amplitude = vector({num})

• Bias

  • simName.solverName.rampName.Bias = vector({num})

Models

Transfer Function

• Numerator

  • simName.solverName.transferFunctionName.Numerator = vector({num})

• Denominator

  • simName.solverName.transferFunctionName.Denominator = vector({num1, num2})

State Space

• A, B, C, D

  • simName.solverName.stateSpaceName.A = matrix({{num1, num2}, {num3, num4})

Other

Saturation

• Minimum

  • simName.solverName.saturationName.Mininum = vector({num})

• Maximum

  • simName.solverName.saturationName.Maximum = vector({num})

Gain

• Value

  • simName.solverName.gainName.Value = vector({num})

Switch

• Selection

  • simName.solverName.switchName.Selection = vector({num})
